2 Pole DC Miniature Circuit Breaker DZ47 C32 500V

The ZHENGRONG DZ47-500V miniature circuit breaker is a compact device for photovoltaic DC power distribution. It can make, carry and break DC circuits while integrated thermal-magnetic trip provides short-circuit and overload protection for PV cables, conductors and equipment — combining load switching, isolation and protection in a single unit.

The 2-pole design protects positive and negative poles simultaneously, with working status visible through the front indicator window. Rated 6000A, it is suitable for DC circuits in solar combiner boxes, PV systems and energy storage equipment.

Design & Operation

The front features a clear status indicator window that allows operators to check the working state and pole connection status of the breaker at a glance without disassembling the device. A streamlined toggle lever on the top provides flexible and comfortable manual switching operation, while precision hollowed-out heat dissipation structures on the shell effectively reduce operating temperature and ensure long-term stable operation.

When tripped or opened, the miniature circuit breaker creates a clear visible break, ensuring reliable electrical isolation and safe equipment maintenance. Internal high-precision copper conductive components and dual protection trip mechanisms are built for stable DC current transmission and sensitive overload & short-circuit protection performance.

Construction & Installation

The housing is molded from high-quality flame-retardant engineering plastic with excellent insulation performance, high temperature resistance and strong mechanical toughness. The status window adopts impact-resistant polycarbonate material, effectively preventing cracking and deformation during long-term operation.

Installation adopts standard rail mounting structure. Precision clamping buckle and positioning grooves enable fast and firm installation on standard DIN rails inside DC distribution boxes, solar combiner boxes and energy storage cabinet systems, realizing convenient assembly and disassembly.

Features

High-reliability DC protection

● — rated 32A & 500V DC for solar PV and energy storage circuit loads.

Switch + isolation + overload/short-circuit protection in one unit

● — make/carry/break, safe isolation and dual electrical protection combined, saving installation space and system cost.

2-pole DC dual protection

● — simultaneous protection of positive and negative DC poles.

Clear status indicator window

● — breaker working status visible at a glance without disassembly.

Precision toggle lever

● — smooth, sensitive and reliable manual switching operation.

Visible break isolation

● — clear disconnection point when tripped or open, ensuring DC system maintenance safety.

Flame-retardant housing

● — excellent insulation, high temperature resistance and mechanical strength.

Robust copper internals

● — high-purity copper conductive components for stable DC current transmission.

Standard DIN rail mounting

● — fast clamping installation on standard rail inside distribution and combiner boxes.

Quality certified

● — CE and IEC60898-2 certified for global PV and energy storage markets.

Application

● Solar photovoltaic combiner boxes and PV power generation systems

● Energy storage cabinets and DC power distribution equipment

● Branch circuit protection in solar power stations and off-grid PV systems

● Overload and short-circuit protection for DC electrical equipment

● Low-voltage DC distribution systems for residential and commercial solar projects

● Safe maintenance isolation with visible break for DC circuits

● Solar installers, energy storage contractors and DC system engineering teams
